| Item Number" |
PEIRC01" |
| Processor" |
HiSilicon Hi3518E V200" |
| Flash" |
25Q128FVSG" |
| Eprom" |
AT88SC0104CA" |
| Compatibility" |
Android (5.1 and higher), iOS (12 and higher)" |
| Communication Technology" |
Wi-Fi (IEEE 802.11b/g/n)" |
| Operating Frequency" |
2.4 GHz" |
| WEP/WPA2 Encryption" |
Support of 64-/128-bit encryption" |
| Server" |
p2p" |
| Horizontal/Vertical Viewing Angle" |
90°/47°" |
| Pan/Tilt (Mechanical)" |
N/A" |
| Pan/Tilt (Remote)" |
350°/120°" |
| Image Sensor Part number" |
GC2033 (GalaxyCore)" |
| Sensor Type" |
1/2.7" CMOS, color" |
| Image Size" |
1920х1080" |
| Scanning" |
Progressive" |
| Focal Length" |
3.6 mm" |
| Minimum Illumination" |
0.5 Lux" |
| Resolution" |
2 MP" |
| Main Stream Video Resolution" |
1920х1080 (Full HD)" |
| Sub-Streams Video Resolution" |
640x480 (VGA)<br/>1280x720 (HD)" |
| Video Frame Rate" |
30fps (For 74.25Hz)" |
| Image Adjustment" |
Brightness <br/>Contrast <br/>Saturation <br/>Mirror Images" |
| Format of Recording" |
AVI" |
| Video Compression Standard" |
H.264" |
| Wi-Fi Chip" |
MT7601UN" |
| Operating Frequency (GHz)" |
2.4 GHz (14-channel)" |
| Smart Antenna Type" |
Standalone" |
| Antenna ZigBee" |
N/A" |
| Support of SD Cards" |
Slot for MicroSD (up to 64Gb)" |
| Mic" |
Built-in" |
| Speaker" |
Built-in (Not active at present time)" |
| IR Filter" |
Built-in" |
| RJ-45 Port" |
Available" |
| Additional Outputs" |
AUX OUT" |
| Night Mode" |
11 IR LEDs, vision of up to 15 m<br/>Peak Wave Length: 850 nm" |
| Installation" |
For indoor installation only<br/>On horizontal or vertical surface (mounting holes available)" |
| Color" |
White" |
| Case Material" |
ABS/PMMA" |
| Certificate" |
CE, EAC, RoHS, UA.TR" |
| Data Protection" |
GDPR Compliance" |
| Angle" |
90°" |
| Distance" |
7 m" |
| Product Size" |
90x112x112 mm" |
| Weight Netto" |
278 g" |
| Specifications" |
5V/2A" |
| Power Consumption" |
5 W (max)" |
| Operating temperatures" |
0°C to +55°C" |
| Operating Humidity" |
20% to 85% (non-condensing)" |
| Non-Operating Temperatures" |
-10°C to +60°C" |
| Non-Operating Humidity" |
0% to 90% (non-condensing)" |
| Warranty Products Returnable" |
Yes" |
| Warranty Term (month)" |
24" |
| Warranty Validation Criteria" |
Serial Number" |
| Warranty Term Notes" |
12 months - for CIS <br/>24 months - for EU, UK, TR <br/>36 months - for NO, SE" |
| Pack Length (mm)" |
201.5 mm" |
| Pack Width (mm)" |
135.5 mm" |
| Pack Height (mm)" |
96.2 mm" |
| Pack Weight Brutto (kg)" |
0.66 kg" |
| Pack Weight Netto (kg)" |
0.47 kg" |
| Pieces in pack" |
1" |
| Box Length (mm)" |
566 mm" |
| Box Width (mm)" |
498 mm" |
| Box Height (mm)" |
230 mm" |
| Box Weight Brutto (kg)" |
14.6 kg" |
| Packs in Box" |
20" |
| Package Type" |
Retail" |
| EAN Code" |
8595248142596" |
| Color box dimensions (mm)" |
201.5x135.5x96.2 mm" |
| Single pack gross weight (kg)" |
0.6605 kg" |
| Carton weight (kg)" |
14.6 kg" |
| Quantity of the boxes per pallet (by air)(pcs)" |
480" |
| Dimensions of pallet (by air)" |
120x100x153 cm" |
| Quantity of the boxes per pallet (by sea)(pcs)" |
640" |
| Dimensions of pallet (by sea)" |
120x100x199 cm" |
| EAN code for master box" |
8595248142602" |
